Under Pressure! Pressure Pipe Tips in Civil 3D – Infrastructure Tuesday



In this session, we will look at and discuss the workflow to create a pressure network in Civil 3D 2021. Specifically, we will review the different ways of creating pressure networks and the Pipe Run component. From there we will generate a pressure network in plan view, and after adding fittings and appurtenances to the network we will add the network into a profile view. We will discuss adding a vertical offset and show labeling and why were those labels come from. Be sure to stay for the Q & A after!
